The VAS 6673A Premium Workstation is the most comprehensive and best-equipped version of the Wieländer+Schill workstation systems, designed for the highest level of body repair and welding work. This premium system integrates the most modern safety, lighting, and extraction technologies, ensuring maximum efficiency and optimal protection for employees.
This configuration stands out from the professional version due to the specially designed, mobile media cart, which offers numerous practical functions for the organized storage and quick access to tools and materials.
The Premium Workstation incorporates the following key elements, which together provide a complete work area:
Comprehensive Protection: The system includes a special welding protection curtain that effectively filters harmful radiation and is equipped with a green welding protection window for better visual conditions.
Integrated Extraction Technology: The main advantage is the built-in extraction system capable of handling various types of pollutants:
Extraction of welding fumes and adhesive vapors.
Effective removal of aluminum dust, CFRP (Carbon Fiber Reinforced Plastic) dust, and steel dust.
High-Quality Structure: The basis of the system is a robust, high-quality aluminum crossbar support system that guarantees stability and a long service life.
Energy-Efficient Lighting: The integrated LED lighting system creates optimal working conditions. The illumination level is extremely high, which is essential for precision work.
Mobile Media Cart: Unlike the professional version, the premium version comes with a mobile cart specially designed for the workstation, offering numerous storage and organization possibilities.
The VAS 6673A Premium Workstation consists of the following components, each meeting the highest quality requirements:
| Parameter | Value |
|---|---|
| Length | 8 m |
| Width | 6 m |
| Höhe | 3.5 m |
The included LED light system ensures adequate illumination of the work area:
Illumination Value: 1000 lux (measured horizontally)
Measuring Height: 1.0 m above the work surface
Measuring Point: The geometric center of the workstation
The delivery package contains the complete, immediately usable premium system, supplied with identifiers:
| Part number | Designation | Description |
|---|---|---|
| 932287 VAS 6777A/1 | Curtain System | Contents: 1 pc aluminum grating system with 4 supports, 2 pcs protective curtain with green welding protection window, and the complete installation package. |
| 932286 VAS 6777A/2 | LED Lighting System | The high-intensity, energy-efficient lighting unit. |
| 932288 VAS 6777A/4 | Mobile Media Cart | The distinguishing element of the premium version, equipped with drawers, shelves, cable and hose reels, sockets, and a telescopic arm holder. |
| 932280NV VAS 6571A/1A | Mobile Dust Extractor | Optimized for steel dust extraction. |
| 932277NV VAS 6572A/2A | Dust Extractor with Spark Arrestor | Specifically designed for extracting aluminum and CFRP dust, supplemented with a spark arrestor to increase safety. |
| 932284 VAS 6571A/1-1A | Telescopic Arm | Support arm ensuring flexible positioning. |
| 932282 VAS 892 003A | Welding Fume Extractor | For the effective extraction of fumes generated during welding processes. |
| 933501 VAS 6760A | Workshop Storage Stand | An auxiliary storage solution for maintaining order in the work area. |
The main distinguishing feature of the VAS 6673A Premium model is the mobile media cart (VAS 6777A/4). This cart not only provides storage but also offers a complete mobility hub in the workshop:
Organized Storage: Numerous drawers and shelves ensure the clear arrangement of tools, consumables, and small parts.
Power Supply and Media: Integrated electrical sockets allow for direct power supply to hand tools right at the point of work.
Cable Management: Built-in cable and hose reels assist in the orderly management of pneumatic and electrical lines, preventing tripping hazards.
Ergonomics: The holder for the telescopic arm ensures that frequently used devices are always at hand but do not obstruct the main work area.
This complex system is an ideal choice for OEM (manufacturer) specifications where the strictest requirements must be met for the safe machining of materials (especially aluminum and CFRP), while employee health protection is also a priority. The 1000 lux illumination guarantees that even the smallest details are perfectly visible during repair work.
