Part number: 497020
This product is an accessory for Wieländer+Schill professional body repair tools, specifically designed for the highest quality welding and repair work. These H-type electrode tips are essential consumables for spot welding technology, guaranteeing precise and reliable joints.
A H-type electrode tips exclusively for X-Trafogun GT-V6 type single-sided spot welding guns. These consumables are crucial for the precise joining of body panels, ensuring factory-quality welds even on hard-to-reach areas.
During the welding process, the electrode tips ensure optimal current transfer and the correct pressure between the two metal sheets, which is essential for a solid and durable resistance spot weld. The special design and material usage minimize wear and maximize service life, even under intensive, professional use.
The product spade shape design, which facilitates access in narrow spaces where traditional round electrodes cannot be used effectively.
These electrode tips meet the strictest industrial requirements thanks to the high-quality base material and precise manufacturing process.
| Property | Value | Note |
|---|---|---|
| Part number | 497020 | Unique Identifier |
| Típus | H Type | Special Design |
| Compatibility | X-Trafogun GT-V6 | Exclusively for this welding gun |
| Material | Zirconium copper | Excellent thermal and electrical conductivity |
| Form | Spade shape | Optimized for tight spaces |
| Wire diameter | 16 mm | Influences the size of the welding spot |
| Dimensions (Length × Width × Height) | 39.5 x 15.95 x 15.95 mm | Precise physical parameters |
| Packaging Unit (PU) | 6 pcs/pack | Economical packaging |
The use of a zirconium-copper alloy offers significant advantages in the field of spot welding:
High Heat Resistance: Capable of withstanding the extreme temperatures generated during welding without softening or deforming.
Excellent Electrical Conductivity: Ensures current transfer to the weld spot with minimal resistance, resulting in a homogeneous and strong joint.
Wear Resistance: The addition of zirconium increases the surface hardness of the electrode, significantly extending its lifespan against frequent contact and friction.
The H-type, flat design (39.5 mm length) is specially optimized for those body parts where standard electrodes do not fit. This geometry allows welding near internal reinforcements, door frames, or subframe points where access is restricted. The 16 mm electrode diameter is ideal for the standard thickness of most modern vehicle body panels.
Wieländer+Schill products are manufactured according to the highest standards of the automotive repair industry. The electrode tips undergo rigorous quality control checks to ensure consistent performance in every welding cycle.
Product compatibility with X-Trafogun GT-V6 ensures seamless system operation thanks to the welding gun, minimizing downtime and increasing workshop efficiency. The 6-piece package ensures you always have a spare on hand when the worn electrode needs replacement.
In summary, the OE 16 mm H-type electrode tips are an ideal choice for bodywork specialists seeking reliable, durable, and precise welding results, especially on narrow or hard-to-reach areas.
