Part number: 311061
This 6-field temperature indicator strip (temperature indicator) is an extremely cost-effective solution for high-volume applications, especially in areas where space is limited. The product's primary goal is to indicate irreversible (non-reversible) temperature overshoots, thus ensuring precise temperature monitoring during critical processes.
This type of temperature indicator is the ideal choice for preparing aluminum parts, for example, before dent removal or straightening work, where precise control of heat treatment is essential to maintain structural integrity and surface quality.
The temperature indicator strip features a horizontal, six-digit scale indicating the measured temperature in degrees Celsius (°C). The indicator system is designed so that when the set maximum temperature is exceeded, the color of the corresponding field irreversibly changes, providing a clear visual indication of the temperature threshold being crossed.
This product is ideally used in the following areas:
Body Repair: Monitoring the heat treatment of aluminum parts before and during welding, soldering, or thermoforming.
Heat treatment processes: Any industrial or workshop process where strict adherence to the maximum permissible temperature is critical.
Quality Assurance: Quick and easy visual check during manufacturing or repair processes.
Thanks to its 6-point design, the strip is extremely space-saving and can therefore be easily placed even in narrow spaces. The packaging (one booklet) contains 10 indicator strips, providing an economical solution for high-volume usage.
The detailed technical specifications of the product are as follows:
| Property | Value | Note |
|---|---|---|
| Number of points | 6 | Horizontal, six-digit scale |
| Maximum temperature | 127 °C | Upper limit of the indicator system |
| Unit of Measure | Celsius (°C) | |
| Indication type | Irreversible (non-reversible) | Indication of overshoot is permanent |
| Package contents | 1 strip (10 measuring strips) | |
| Length | 80 mm | |
| Width | 50 mm | |
| Höhe | 1 mm | |
| Material | Plastic (Plastic, kunststoff) | Durable Design |
When purchasing the product, you will receive the following:
The Wieländer+Schill temperature indicator strip combines reliability and easy handling.
Precise Temperature Monitoring: The 6-point scale allows for finer tracking of the temperature profile before reaching the maximum value.
Visual Proof: Provides immediate, clear visual feedback on adherence to the temperature protocol, thus reducing the risk of faulty components.
Easy Application: The thin, plastic-based strips can be easily applied to the surface to be tested.
Ideal for Aluminum: Specifically recommended for checking the heat treatment of aluminum components, where overheating can damage the material structure (e.g., reduction in strength).
This product is part of the wide range of Wieländer+Schill welding technology accessories, which guarantee the precision and quality required for professional body repair work.
