Part number: 637123
This high-quality HSS (High-Speed Steel) fine file features a specially designed, disc-shaped head, primarily developed for the post-processing, refining, and deburring of weld seams. As a tool belonging to the Wieländer+Schill product family, it is the optimal choice for precision metalworking applications where surface quality and dimensional accuracy are crucial.
The HSS fine file with article number 637123 is the ideal tool for smoothing weld seams generated in bodywork construction and general metal processing. The disc-shaped head design allows access to hard-to-reach surfaces while ensuring efficient material removal without leaving excessively deep marks on the workpiece.
The use of High-Speed Steel (HSS) guarantees the tool's long lifespan and excellent wear resistance, even under intensive use. The fine teeth ensure a smooth, even surface, minimizing the need for subsequent grinding or polishing phases.
Main Advantages:
Precision post-processing: Ideally suited for fine-tuning weld seams and deburring.
Long lifespan: HSS material quality for durability and tool longevity.
Ergonomic design: The disc shape ensures optimal access to complex geometries.
Compatibility: Allows use with standard shank systems of 3 mm diameter.
The table below details the precise physical and material characteristics of the HSS fine file:
| Property | Value | Note |
|---|---|---|
| Part number | 637123 | Unique Identifier |
| Material | HSS (High-Speed Steel) | Excellent heat and wear resistance |
| Head shape | Disc shape | For weld seam finishing |
| Head length | 2.6 mm | Cutting surface thickness |
| Total length | 33 mm | Total length of the tool |
| Shank diameter | 3 mm | Standard Collet Size |
| Dimensions (Length x Width x Height) | 11.8 x 11.8 x 32.7 mm | Overall extension of the head and shank |
| Weight | 0.0056 kg | Light weight for precise maneuverability |
| Package contents | 1 piece (1 stück, 1 piece) |
This fine file belongs to the Wieländer+Schill Separating Tools category, further classified under the Sanding & Milling sub-group. The tool is designed to withstand the stress resulting from high-speed rotation, while the HSS material ensures the tool does not overheat too quickly, which could lead to a deterioration of workpiece quality.
The 3 mm shank diameter ensures stable mounting of the tool in the appropriate drive unit (e.g., in pneumatic or electric grinding/milling machines). The 33 mm overall length provides sufficient working room for the operator, while the 2.6 mm head thickness is ideal for the fine removal of thinner material layers or weld seams.
The disc-shaped head is particularly useful in areas where projecting material needs to be removed while preserving the base surface of the workpiece. The fine file teeth guarantee that the surface remains smooth, thus reducing vibration and noise in subsequent machining phases.
This product is designed for professional body repair technologies and is the ideal accessory for any workshop requiring high-quality and reliable tools for metalworking processes. The product complies with strict quality requirements, substantiated by the manufacturer's ISO 9001 and ISO 14001 certifications.
