The InvertaSpot GT-C AUTOMATIC A tip technology spot welding system specifically designed for the efficient and reliable welding of high-strength and ultra-high-strength steels (HSS and UHSS). This equipment is an ideal choice for modern automotive repairs where body panel material quality requires maximum precision and process control.
The main strength of the GT-C model lies in full automation which optimizes energy consumption and guarantees consistent weld quality. The device is capable of automatically detecting the conditions prevailing at the welding spot, dynamically adjusting the welding parameters accordingly, and continuously monitoring the entire welding cycle. This advanced intelligence ensures that every single weld meets strict OEM requirements, especially Mercedes-Benz (MB) specifications.
There is also an option for experts to use manual mode, which allows free setting of welding parameters, providing flexibility for special or non-standard repair tasks.
Intelligent Automation: Automatic detection and parameter setting of the welding process, minimizing the possibility of human error and maximizing energy efficiency.
High-Strength Material Handling: Specifically suitable for welding high and ultra-high-strength steels (HSS/UHSS), which are essential for restoring the structural integrity of modern vehicles.
Manual Control: Free parameter setting option for expert users.
Excellent Energy Efficiency: Extremely energy-saving operation thanks to full automation.
Robust Construction: Powder-coated surface treatment that resists workshop conditions.
OEM Compatibility: Specifically recommended and optimized for the repair of Mercedes-Benz vehicles.
The extremely detailed technical specifications of the InvertaSpot GT-C AUTOMATIC ensure precise and reliable performance:
| Parameter | Value | Note |
|---|---|---|
| Part number | 932436 | |
| Mains Voltage | 3 ~ 400 V | |
| Frequency | 50 – 60 Hz (+/- 10 %) | |
| Network Connection (Copper) | 4 × 6 mm² | |
| Rated Current Draw (Fuse) | 32 A (slow) | |
| No-load Voltage | 12 V | |
| Current Adjustment Range | 0 – 13 kA , 0 – 13 kA | Two independent ranges |
| Welding Gun/Electrode Force (Max.) | 6.5 kN | |
| Operating Pressure (Air) | 6 – 8 bar | |
| Air Quality | ISO 8573-1 | |
| Flow Rate (Cooling) | 5 l/min | |
| Protection Class | IP 21 | |
| Noise Level (Sound Pressure Level) | 70 dB(A) | |
| Dimensions (Length × Width × Height) | 810 x 560 x 750 mm | |
| Weight | 119 kg | |
| Materials | Plastic, Sheet Steel, Steel | |
| Casing | Powder-coated | |
| Tank Capacity | 80 liters | |
| Conformity Declaration | According to 2006/42/EC | CE Conformity |
For complete operation, the InvertaSpot GT-C AUTOMATIC is delivered with the following basic and supplementary components:
1 pc 495620 C-Arm No. 1 | Standard | 150 × 70 mm | GT
1 pc 495625 C-Arm No. 3 | 150 × 450 mm | GT
1 pc 495615 C-Arm No. 4 | 350 × 450 mm | GT
1 pc 474004 Balancer Tube GT | 630 mm | basalt grey
1 pc 474014 Balancer Arm GT | basalt grey
1 pc 478060 Balancer Pulley | GT
1 pc 498085 Spring Balancer | with 9-15 kg load capacity
1 pc 474017 Insulating Strap with Carabiner | GT
1 pc 474250 Allen Key Set GT | 2 pieces
1 pc Electrode Caps | Ø 16 mm | Type A-32 | Pack: 10 pcs
1 pc 498003 Electrode Cap Remover
1 pc 474028 Support for C-Arms
1 pc 474085 Cable Support for InvertaSpot GT-C
1 pc 478041 Cable Support GT | V2
1 pc 474007 Wheel Set | GT
This complex assembly ensures that the equipment is immediately deployable for the most demanding body repair tasks. Returning the registration card is recommended for comprehensive support.
