This professional cartridge heater from Wieländer+Schill offers an excellent solution for bodywork and repair jobs where maintaining the optimal temperature of the adhesives (cartridges) is essential for a precise and durable bond. The device is designed to accommodate two cartridges simultaneously, ensuring continuous workflow.
The cartridge heater with part number 831113 meets the highest quality standards, is manufactured in Germany, and carries the CE/RoHS conformity mark. A key element of the device is precise temperature control, which guarantees the ideal viscosity of the materials used.
Dual Capacity: Suitable for heating two cartridges simultaneously, thereby increasing workshop efficiency.
Continuous Temperature Control: The temperature can be adjusted steplessly within the desired range.
Kivételes Pontosság: Maintains the set temperature within an extremely narrow tolerance range, with an accuracy of ±1 °C.
Digital Feedback: The digital display continuously shows the set target temperature and heating status, ensuring the user always has up-to-date information.
Optimized Sensor Position: The temperature sensor is located at the upper part of the two tubes, ensuring even and precise temperature control along the entire length of the cartridge.
High Heating Power: It has a heating capacity of 200 W, enabling fast and reliable warm-up.
Robust Construction: It features compact dimensions and a weight of 3.0 kg, providing stability and easy handling.
The Wieländer+Schill cartridge heater delivers outstanding performance in terms of key technical parameters, making it an ideal choice for professional body shops.
| Parameter | Value | Note |
|---|---|---|
| Part number | 831113 | |
| Number of Cartridges | 2 | |
| Temperature setting range | 0 °C – 160 °C | Infinitely variable |
| Control Accuracy | ±1 °C | |
| Maximum Operating Temperature | 160 °C | |
| Heating Power | 200 W | |
| Power Consumption (Max.) | 230 W | |
| Mains voltage | 1 ~ 230 V | |
| Frequency | 50 Hz | |
| Fuse | 1 A | |
| Dimensions (Length x Width x Height) | 230 x 150 x 100 mm | |
| Weight | 3.0 kg | |
| Place of manufacture | Germany | |
| Mark of conformity | CE/RoHS |
This heating device is an essential tool for all applications where two-component adhesives (e.g., epoxies, polyurethanes) are used in cartridge packaging. Ensuring the correct temperature is critical for optimizing the viscosity of the adhesives, which directly affects curing time, adhesion, and the final mechanical strength of the bond. The adjustable range starting from 20 °C provides flexibility for meeting the temperature requirements specified by different types and manufacturers of adhesives.
The digital display and precise regulation minimize user errors, while the two-cartridge design ensures that the repair process is not interrupted by cartridge changes. The reliability and durability of the device are guaranteed thanks to German manufacturing quality.
Wieländer+Schill is committed to the highest quality standards, which are evidenced by the ISO 9001 (Quality Management System) and ISO 14001 (Environmental Management System) certificates. This cartridge heater was also manufactured according to these principles, ensuring a long service life and reliable operation even in the most intensive workshop environments. CE and RoHS compliance guarantees that the product meets European safety, health, and environmental regulations.
