This professional, mechanically operated flanging pliers (also known as a fitting or crimping plier) from Wieländer+Schill is excellently suited for bodywork and sheet metal working tasks. It is specifically designed to allow sheets to be precisely fitted together with minimal force, even if the workpiece has a curved or profiled surface. This tool is an essential device during car body repair to ensure a perfect fit and professional jointing.
The mechanical operation guarantees reliable and consistent performance, regardless of the electrical power supply or the availability of pneumatic systems. The design of the tool allows work to be done in tight spaces and on surfaces with complex geometry.
Könnyű Kezelhetőség: Thanks to the mechanical operation, the tool is extremely simple to use, requiring minimal physical effort for precise fitting.
Precise Fitting: Enables the accurate placement of sheets onto each other, which is essential for quality welding or adhesive preparation.
Suitable for Curved Surfaces Too: Specifically suitable for working along curves, radii, and other profiled surfaces where conventional tools struggle.
Durable Design: Thanks to the metal material, it ensures a long service life and high resistance in the workshop environment.
Kompakt Méretek: The length of 230 mm and the overall size of 220 x 100 x 30 mm ensure optimal maneuverability.
The table below details the specifications of the mechanical flanging pliers:
| Property | Value | Note |
|---|---|---|
| Part number | 561023 | Product Identifier |
| Application | Flanging/Fitting of Curved Surfaces | |
| Type of Operation | Mechanical | No external power source required |
| Clamping/Clamping Range | 0 – 0.8 mm | Maximum manageable sheet thickness |
| Work Window | 2 x 20 mm | The effective working zone of the tool |
| Length | 230 mm | Total length of the tool |
| Dimensions (L x W x H) | 220 x 100 x 30 mm | Overall external dimensions |
| Material | Metal | Robust construction |
| Weight | 0.350 kg | Low weight for comfortable use |
| Package contents | 1 piece (1 stück) |
This flanging plier is the ideal choice for any professional working in the following areas:
Body Repair: Especially useful in areas where two sheets need to be precisely joined together (e.g., for splicing, installing repair elements), particularly on curved parts of the bodywork (e.g., wheel arches, roof curves).
Sheet Metal Working: During general sheet metal work where flanging or fitting is essential for a strong and aesthetic bond.
Handling Profiled Materials: Any workpiece that does not have a flat surface and requires precise fitting.
The tool ensures that the fitting points of the sheets match perfectly, minimizing gaps and facilitating subsequent processing steps such as spot welding or adhesive bonding. The maximum clamping range of 0.8 mm ideally covers the sheet thickness of most passenger car bodies.
The quality of Wieländer+Schill products is also supported by ISO 9001 and ISO 14001 certifications, ensuring continuous quality management and environmentally conscious manufacturing processes. This mechanical crimping tool is a guarantee of reliability and precision during everyday workshop work.
