The PIUSI PANTHER AC series alternating current (AC) diesel fuel transfer pump is one of PIUSI's iconic products, designed for the highest performance and durability. Available in PANTHER AC 56, 72, and 90 versions, it offers an ideal solution for the most demanding industrial, agricultural, logistics, construction, and fleet management environments.
This pump is a direct development by the PIUSI engineering team, ensuring reliability and long life, even under extreme conditions. The product proudly bears the „MADE IN ITALY QUALITY” certification.
PANTHER AC pumps are perfectly suited for pumping diesel (including HVO and XTL fuels) in fixed fuel storage systems, fleet fuel supply stations, and other industrial applications.
Compact and Robust Design: The pump features a massive cast iron body, providing exceptional resistance to mechanical stress and corrosion.
Easy Installation and Operation: Thanks to the „READY TO USE” design, installation is simple, requiring minimal preparation.
Excellent Low-Temperature Performance: The pump operates reliably even at low temperatures, ensuring continuous operation even in winter.
Integrated Filter: The built-in filter protects the pump mechanism from contaminants, thus increasing lifespan and reliability.
Precise Flow Control: The built-in by-pass valve allows for precise regulation of the amount of fuel pumped during the transfer operation.
Thermal Protection: The motor is equipped with thermal protection against overload, which increases safety and durability.
The PANTHER AC is a rotary vane, self-priming pump. The careful selection of internal components ensures excellent sealing and long life.
| Component | Material/Specification |
|---|---|
| Pump Type | Rotary vane, self-priming |
| Rotor | Sintered steel |
| Vanes | Acetal resin |
| Motor Type | Induction motor |
| Motor Casing | Alu |
| Operating Cycle | Maximum 30 minutes of continuous operation |
| Protection | Thermal protection (against overload) |
| Filter | Integrated |
| By-pass Valve | Yes, for flow regulation |
| Connections | Flanges (optionally orderable) |
The PANTHER AC pumps are available in three main performance categories, indicating the maximum flow rate:
| Design | Maximum Flow Rate |
|---|---|
| PANTHER 56 | Up to 56 liters/minute |
| PANTHER 72 | Up to 72 liters/minute |
| PANTHER 90 | Up to 90 liters/minute |
The pumps are available in different electrical configurations to comply with regional grid standards (e.g., 230V/50Hz, 230V/60Hz, 400V/50Hz).
Due to the versatility of the PANTHER AC series, it can be widely applied in:
Agriculture: High-capacity fuel supply for machinery fleets.
Logistics & Transport: Quick and reliable refueling for vehicle fleets.
Mining & Construction: Reliable operation in harsh environments.
Industrial Plants: Fixed fuel transfer systems.
Automotive Service Centers and Workshops: Professional diesel transfer solutions.
PIUSI offers the PANTHER AC pumps in various voltage and frequency combinations, including the flanged connection option on some models.
| Product code | Description | Note |
|---|---|---|
| 000731000 | PANTHER 56 230V/60Hz | |
| 000732000 | PANTHER 72 230V/50Hz | |
| 000733000 | PANTHER 56 400V/50Hz | |
| 000735000 | PANTHER 72 400V/50Hz | |
| F00730000 | PANTHER 56 230V/50Hz PIUSI | |
| F0073302A | PANTHER 90 230V/50Hz + FLANGE | With flanged connection |
The PIUSI PANTHER AC pumps represent the perfect fusion of quality, durability, and high performance, ensuring the smooth operation of fuel refueling processes.
