C-Yoke GC 140/240 SC

C-Kar GC 140/240 SC – Professional Riveter Accessory for the XSeries

This detailed product description is for the C-Yoke GC 140/240 SC presents an accessory specifically developed for the Wieländer+Schill XSeries professional riveting technology. This tool is an essential accessory for precise and efficient body repair work, especially when working heights or reaches beyond the standard range are required.

The C-Kar GC 140/240 SC combines reliability and flexibility, ensuring optimal riveting conditions even in the most difficult-to-reach spots.

Product Description and Key Features

A C-Yoke GC 140/240 SC a special C-arm (C-shaped arm) unit designed for the XSeries riveting systems. The set includes the C-arm along with two extension accessories of different lengths: one 60 mm and one 93 mm extension. These accessories significantly increase the flexibility and adaptability of the tool for various vehicle structural components.

This C-arm design allows the positioning of the riveting head in areas where conventional straight arms cannot reach, such as near narrow internal curves or complex joint points. The robust construction guarantees stable support and precise force transmission during the riveting process.

Benefits for the User:

• Increased Accessibility: The C-arm shape and the included extensions make it possible to work in hard-to-reach places, minimizing the need to disassemble the vehicle body.

• System Compatibility: Fully integrable into the Wieländer+Schill XSeries riveting technology, ensuring seamless operation.

• Flexible Configuration: The quick and easy change between the 60 mm and 93 mm extensions allows for immediate adaptation to changing work environments.

• Stability & Precision: The massive design guarantees that the riveting force is directed precisely to the desired point, which is essential for factory-quality repairs.

Technical Data

The table below summarizes the critical technical parameters of the C-Kar GC 140/240 SC and its accompanying accessories.

Detailed Accessory Overview

The efficiency of the C-Arm GC 140/240 SC is further increased by the included or optionally available accessories. The set includes the following:

1. 93 mm Extension for SSC 35/25

This extension is specifically optimized for combined use with the SSC 35/25 short-stroke cylinder, alongside the C-Arm GC 140/240.

• Part number: 700517

• Function: Increases the reach for the SSC 35/25 cylinder when used in conjunction with the C-Arm. Ideal for deeper or hard-to-reach points.

2. 60 mm Extension for PushPull PP 90

This accessory is intended for concurrent application with the PushPull PP 90 unit, also within the frame of the C-Arm GC 140/240.

• Part number: 700153

• Function: Ensures the necessary distance and positioning for working with the PP 90 riveter in the C-Arm configuration.

3. Handle for Fixed Magnets and C-Arms (Red)

Although it does not directly affect the riveting function, this ergonomic accessory significantly improves handling and the speed of securing components.

• Part number: 881341

• Function: A red handle that facilitates the quick and fatigue-free fixing and adjustment of fastening elements (such as fixed magnets and C-Arms).

Application Areas

The C-Arm GC 140/240 SC is the ideal choice for any professional body shop that needs to perform:

1. Chassis and Underbody Repairs: Reaching tight spots on the lower part of the vehicle or on frame structures.

2. Door Frames and Pillars: Riveting internal reinforcements where standard tools cannot fit between panel layers.

3. Complex Joints: For modern vehicles where multi-layer materials and strict design constraints require specialized tooling.

4. Repairs According to OEM Specifications: Ensures compliance with factory-quality, monitored riveting parameters thanks to the stability of the C-Arm.

The Wieländer+Schill C-Arm GC 140/240 SC is the cornerstone of precision body repair technology, increasing workshop efficiency and the quality of repairs.
