The Consul 4-Post Lift 4.70 model is a robust and reliable lifting solution specifically designed for lifting passenger cars and commercial vehicles up to 7,000 kg total weight, as well as for wheel alignment. Thanks to its extra-long platforms, it also offers an ideal solution for servicing long-wheelbase vehicles. This lift is the ideal choice for professional workshop environments due to Consul's quality engineering and strict adherence to safety regulations.
This 4-post lift includes several design features that increase efficiency, safety, and usability during daily workshop work:
Silent Hydraulics: Low-noise, oil-submerged hydraulic drive ensures smooth and quiet operation.
Electro-hydraulic Control: Precise and reliable control system for easy handling.
Operating Direction: The lift can be controlled from the rear left position, corresponding to the vehicle's installation direction.
Main Safety Switch: It is equipped with a separate main switch compliant with CE regulations, which can be locked if necessary.
Acoustic Step Protection: Increased safety during the lowering process.
Hydraulic Tensioning Cylinder: The basis for the reliable operation of the system.
Safety Features: Tensioned cable, protection against cable breakage, and anti-roll-back protection guarantee maximum safety.
Sports Car Compatibility: The platforms are equipped with 1,000 mm ramps, ideal for driving up sports vehicles.
Adjustable Platform: One platform is fully adjustable, equipped with a locking mechanism. Optionally available in a version with roller guide.
Integrated Jack Beam Rail: The rail integrated into the platform enables the easy use of auxiliary jack beams.
Pneumatic Locking Control: Central control for the pneumatic clamping system (8 bar pressure required).
Fine Adjustment Clamping: Clamping rods located every 100 mm across the entire lifting height ensure precise positioning.
Certifications: IP 54 protection class, GS certificate, DIN EN 1493 and CE approval.
If the lift is ordered with the runway kit, the following additional functions are also available:
Integrated, full-size turning plates.
Turning plate system, suitable for accommodating turning plates up to 50 mm high, with continuous turning plate cover.
The technical parameters of the Consul 4-post lift 4.70 can be found in detail below:
| Characteristic | Value | Note |
|---|---|---|
| Part Number (SKU) | 730135 | |
| Manufacturer Number (HAN) | 473160 | |
| Category | 4-Post Lifts | |
| Rated load capacity | 7.000 kg | For passenger and light commercial vehicles |
| Lifting height | ca. 1.980 mm | |
| Lifting Time (loaded) | approx. 55 seconds | |
| Set-up width | 3,505 mm | |
| Drive-up height | approx. 185 mm / approx. 235 mm (AM) | AM: optional (e.g., with lifting platform) |
| Distance between runways | ca. 2.945 mm | |
| Power supply | 400 V / 50 Hz | Three-phase mains |
| Drive Power | 3.0 kW | |
| Fuse Protection | 20.0 A slow-blow | |
| Oil quantity | approx. 9 liters | |
| Runway width | 630 mm | |
| Runway length | 6,240 mm | |
| Runway distance (adjustable) | approx. 750 – 1,200 mm | |
| Overall height | ca. 2.610 mm | |
| Total length with ramps | 7.360 mm | Including approach ramps |
The Consul 4.70 lift can be flexibly expanded with accessories tailored to workshop requirements:
This kit is specifically designed for lifts without wheel-free capability. It is compatible with a platform width of 630 mm and a platform length of 6,240 mm. It enables precise 3D wheel alignment.
These adapters can be retrofitted to 4-post lifts and are specially optimized for the Beissbarth Easy 3D wheel alignment kit. The set contains 2 adapters.
Anti-slip coating applicable to the surface of the platforms, significantly increasing grip. Important: This coating can only be requested during factory assembly; it is not suitable for retrofitting.
Available in various versions, each including an anti-roll-off function:
For the built-in version (without wheel alignment equipment): 1 set = 2 pieces.
For the built-in version (with wheel alignment equipment): 1 set = 2 pieces.
For the conventional (non-built-in) version: Ramp approx. 1,000 mm long, 1 set = 2 pieces.
Conventional, straight, extended version: Ramp approx. 1,500 mm long, 1 set = 2 pieces.
Special lift platform that enables the convenient use of headlight tester equipment on the lift.
Detailed technical and installation documentation is available for the product:
Catalogue (Brochure): Detailed overview of the C-Line 4-post lifts (from 4.55 onwards).
Installation plan: Precise guide for the professional installation of the Consul 4.70 lift.
The Consul 4-post lift 4.70 is the ideal choice for workshops looking for reliable, high-capacity, and long-lasting lifting equipment to service modern vehicle fleets.
