Part number: 700273
This detailed product description presents the G1 type die plate holder, which is part of the Wieländer+Schill professional automotive specialist tool range, developed specifically for precise and reliable riveting technologies (XSeries). This component is crucial for ensuring the stability and accuracy of the tooling during the application of the die plates.
The G1 die plate holder (Counterholder for die plate) is an important accessory for the Wieländer+Schill XSeries professional riveting technology. It is specifically designed for fixing and supporting the die plates, ensuring optimal positioning of the workpieces and accurate transmission of forces during the riveting process. Designed for die plates with a 6 mm diameter, this part is essential for high-quality execution of body repair work.
The product design guarantees stable seating of the tools, minimizing vibration and displacement of the tool even under high stress loads. This stability directly contributes to perfect joint quality and the durability of the repaired parts.
The G1 die plate holder is manufactured using precision production processes to meet the strictest industrial requirements. The table below summarizes the most important physical characteristics of the product:
| Property | Value | Note |
|---|---|---|
| Product Name | G1 Die Plate Holder | Counterholder for die plate |
| Part number | 700273 | Unique Identifier |
| Compatible Die Plate Diameter | Ø 6 mm | Specifically for 6 mm die plates |
| Length (L) | 25 mm | Product length dimension |
| Width (W) | 18 mm | Product width dimension |
| Height (H) | 49 mm | Product height dimension |
| Series | XSeries | Professional riveting technology |
Precise Geometry: The component, manufactured with tight tolerances, ensures a perfect fit with the appropriate die plates and the support system of the riveting machines.
Robust Design: The use of durable material guarantees a long service life, even in intensive, high-load workshop environments.
Optimized Dimensions: The dimensions of 25 x 18 x 49 mm ensure the necessary mechanical stability without being unnecessarily large or heavy.
System Compatibility: Fully integrable into the Wieländer+Schill XSeries professional riveting systems, ensuring a seamless workflow.
Using the G1 die plate holder brings several advantages for automotive repair professionals:
Increased Accuracy: The firm support of the tools minimizes inaccuracies that occur during the riveting process, which is essential for repairing body panels on modern vehicles.
Faster Work Execution: Reliable fastening reduces the need for repeated adjustments, thus increasing workshop efficiency.
Tool Protection: Proper support prevents premature wear or damage to the die plates, thereby reducing maintenance costs.
OEM Quality: Wieländer+Schill products comply with strict quality specifications, ensuring that repairs meet manufacturer expectations.
This component reflects Wieländer+Schill's commitment in the field of professional body repair tools, where every single part contributes to the quality of the final work. The G1 anvil, item number 700273, is an indispensable tool for every professional performing the highest level of riveting work.
