The PIUSI P60:1 BOOSTER is an excellent quality, air-operated piston pump specifically designed for dispensing greases and viscous oils at high pressure in the most demanding industrial environments. This robust equipment guarantees reliability and long service life, even under the harshest operating conditions.
The P60:1 BOOSTER pump offers an ideal solution for situations requiring high-pressure, precise dispensing, whether for short or long-distance transfer. Thanks to its high 60:1 ratio, it is capable of generating extremely high pressure, ensuring the effective transfer of viscous materials.
Main Advantages:
Double Effect Operation: The pump is equipped with a double-effect pneumatic cylinder, which ensures a smooth, uninterrupted material flow, minimizing pressure fluctuation. This design results in better performance and lower compressed air consumption.
Exceptional Durability: PIUSI used the most suitable materials during manufacturing to guarantee long service life and continuous high performance.
Quiet Operation: The pump's special design – including the pneumatic exchanger and the three-stage air exhaust system – minimizes mechanical wear and noise level. The operating noise is only 77 dB, which significantly contributes to workplace comfort.
Maintenance-Free: Due to the absence of mechanically impacting, wearing parts, the pump requires minimal maintenance.
Excellent Material Protection: The composite material housing resists oxidation and also provides protection against particle ingress.
Non-Metallic Diffuser: The non-metallic diffuser ensures clean material flow and prevents contamination.
The PIUSI P60:1 BOOSTER pump can be widely used in the following sectors:
Vehicle Services and Garages: Dispensing of high-viscosity greases and oils to lubrication points.
Mining & Construction: Continuous lubrication of heavy machinery and equipment under extreme conditions.
General Industrial Lubrication: High-pressure greasing of factory machinery, conveyor belts, and other equipment.
The performance and reliability of the P60:1 BOOSTER pump are supported by the following technical parameters:
| Characteristic | Value | Note |
|---|---|---|
| Ratio | 60:1 | To achieve extremely high pressure. |
| Maximum Operating Pressure | 460 bar | Ideal for viscous greases. |
| Noise Level | 77 dB | Super-smooth, quiet operation. |
| Drive | Pneumatic (Air Operated) | |
| Cylinder Design | Double Acting (Double Effect) | Continuous material flow. |
| Diffuser Material | Metal-free | Protection against particles. |
| Body Material | Composite material | Oxidation-free, durable. |
| Maintenance | Maintenance-free | Without abrasive mechanical parts. |
The PIUSI P60:1 BOOSTER pump is available in different lengths (and thus capacities) to optimally fit user requirements.
| Product code | Description |
|---|---|
| F0021605A | PIUSI P60:1 470 AIR OPERATED PUMP GREASE |
| F0021606A | PIUSI P60:1 730 AIR OPERATED PUMP GREASE |
| F0021607A | PIUSI P60:1 940 AIR OPERATED PUMP GREASE |
For maximum efficiency and flexibility, numerous accessories are available:
Dispensing and Hose Systems:
Grease gun with rigid tube (GREASE GUN RIGID HOSE)
Grease gun with flexible hose, with 4-jaw coupler (GREASE GUN FLEX HOSE 4-JAW COUPLER)
Hoses: Hoses of various lengths (2m, 4m, 6m) 1/4″x1/4″ M/F Dn6 EN857 2SC standard.
Connectors: 1/4″ M/F swivel joints (in ‘Z’ and standard version).
Drum Handling Solutions:
Two-wheel trolley For 12-30 kg drums (2-WHEELS TROLLEY FOR 12-30KG DRUMS).
Four-wheel trolleys for drums of different sizes (20-60 kg, 180-200 kg).
Follower Plates: Follower plates optimized for drums of various capacities (from 12/16 kg up to 180/200 kg), which ensure continuous material supply to the pump and prevent air suction.
Covers: Protective covers that fit the drum to prevent contamination.
Air Preparation Units:
Pressure regulator with manometer (in 1/4″ and 1/2″ sizes).
Filter-pressure regulator with manometer (in 1/4″ and 1/2″ sizes) for improving compressed air quality.
The PIUSI P60:1 BOOSTER is the cornerstone of reliable, high-performance grease dispensing, minimizing downtime and maximizing maintenance efficiency in industrial facilities.
