The J.A. Becker & Söhne V 5345-2/40 type, 15 kW single-stage air compressor is an excellent choice for those seeking a reliable, high-performance compressed air generation solution. This model is flexibly configurable to meet various pressure and flow rate requirements, providing an operating pressure range between 20 and 40 bar and a flow rate between 61.8 and 154.8 m³/h.
JAB compressors are not „off-the-shelf products”; the design prioritized the highest quality and efficiency, guaranteeing long service life and low maintenance requirements.
This compressor family has the following outstanding characteristics:
High-efficiency cooling: Excellent heat management ensures the optimal operating temperature, thereby maximizing efficiency and extending service life.
Teljesen automatikus ürítés: The built-in automatic oiling system simplifies maintenance and ensures the system's optimal condition even during downtimes.
Long maintenance intervals: Thanks to the robust construction and quality components, maintenance cycles have been significantly extended, thus reducing downtime and operating costs.
Outstanding quality in every respect: The product reflects the engineering precision of J.A. Becker & Söhne, ensuring reliable and continuous operation.
The V 5345-2/40 model is a single-stage, 2-cylinder design, operating at 1500 rpm. The compressor is available in several configurations, depending on the inlet pressure and the desired maximum operating pressure.
The table below details the different performance specifications:
| Inlet Pressure (Inlet Pressure) | Maximum Operating Pressure (Max. Operating Pressure) | Volume Flow (Volume Flow) |
|---|---|---|
| 7.5 bar | 30 bar | 1520 l/min |
| 7.5 bar | 40 bar | 1450 l/min |
| 10 bar | 20 bar | 2050 l/min |
| 10 bar | 30 bar | 1950 l/min |
| 10 bar | 40 bar | 1865 l/min |
| 13 bar | 20 bar | 2580 l/min |
| 13 bar | 30 bar | 2460 l/min |
| 13 bar | 40 bar | 2340 l/min |
General Specifications:
Power: 15 kW
Number of stages: 1 compression stage
Number of cylinders: 2
Speed: 1.500 rpm
Flow rate range: 61.8 – 154.8 m³/h (converted based on specifications)
Operating pressure range: 20 – 40 bar
This compressor is the ideal choice for industrial applications requiring high pressure but a relatively medium volume flow of compressed air. The maximum pressure capability of 40 bar can be particularly advantageous when driving special hydraulic or pneumatic systems where conventional compressors are insufficient.
J.A. Becker & Söhne is committed to avoiding standard solutions, designing every unit to meet the highest industrial demands. The excellent cooling system ensures that the compressor operates stably even under intensive load, minimizing heat-induced performance loss.
Detailed data sheets and brochures are available for the product to provide further technical details. Thanks to its robust design and components engineered for a long service life, the V 5345-2/40 offers a cost-effective solution for compressed air generation over the long term.
