The J.A. Becker & Söhne V 5780/300 NG4 model is a piston technology, four-stage natural gas compressor specifically designed for the efficient supply of gas feed and compression tasks. This equipment offers an ideal solution for industrial applications requiring reliable, high-pressure natural gas supply. The unit ensures outstanding performance, long service life, and low maintenance requirements.
The V 5780/300 NG4 compressor is not an „off-the-shelf” product, but a carefully designed, premium category solution with several advantageous features:
Outstandingly Efficient Cooling: The compressor's advanced cooling system guarantees optimal operating temperature even under intense load. This not only increases the efficiency of gas compression but also significantly contributes to the machine's long service life by minimizing thermal stress.
Fully Automatic Discharge: The equipment features an automatic start-up function which simplifies operation and ensures continuous, uninterrupted functioning. This function is crucial for safe and reliable gas handling.
Long Maintenance Intervals: Thanks to its robust construction and the use of quality components, the V 5780/300 NG4 allows for extremely long maintenance intervals. This reduces downtime and optimizes operating costs.
First-Class Quality In Every Respect: J.A. Becker & Söhne's commitment to quality is reflected in every detail of the unit, ensuring reliability even in the most demanding environments.
The performance and parameters of the V 5780/300 NG4 compressor are detailed in the table below:
| Parameter | Value | Note |
|---|---|---|
| Inlet Pressure (Inlet Pressure) | 1.5 / 3 / 4 bar | Support for multiple inlet pressure ranges |
| Volume Flow (Volume Flow) | 867 / 1,350 / 1,800 l/min | Volume flow rate adjusted to inlet pressure |
| Maximum Operating Pressure (Max. Operating Pressure) | 300 bar | For high-pressure applications |
| Pressure stages / Number of cylinders | 4 / 4 | Four-stage compression system |
| Electric Motor Power | 30 kW | Drive unit power |
| Rotational Speed (Rotational Speed) | 1,500 rpm | Electric Motor Speed |
| Gas type | Natural Gas (Natural Gas) | Optimized specifically for natural gas compression |
The flexibility of the compressor is well demonstrated by the fact that the volume flow dynamically adjusts as the inlet pressure changes:
Lower Inlet Pressure (1.5 bar): Available volume flow rate: 867 l/min.
Medium Inlet Pressure (3 bar): Available flow rate: 1,350 l/min.
Higher Inlet Pressure (4 bar): Available flow rate: 1,800 l/min.
This scalability ensures that the V 5780/300 NG4 can adapt to varying network conditions while continuously operating at the maximum pressure of 300 bar.
The V 5780/300 NG4 compressor is an ideal choice in areas where natural gas needs to be compressed to high pressure, for example:
Filling of gas reservoirs: The 300 bar final pressure enables the efficient filling of large storage systems.
Automotive Fuel Gas (CNG) Stations: The high flow rate and high pressure create ideal conditions for fast and efficient vehicle refueling.
Industrial Processes: Supplying production processes that require large quantities of high-pressure natural gas.
Significant heat is generated during the four-stage compression. The cooling solution applied by J.A. Becker & Söhne highly efficient cooling solution is of critical importance. This system ensures that the gas temperature remains at an optimal level between each stage. The reduced temperature not only increases energy efficiency by reducing the compression work but also protects the seals and pistons from excessive heat, thereby extending their service life.
A fully automatic blow-off function minimizes the need for user intervention. This system intelligently manages pressure differentials and condensate removal, ensuring the compressor always operates with the most suitable parameters.
A long maintenance intervals is the result of precision manufacturing. Strict quality control and the use of materials of excellent quality guarantee that the equipment operates reliably with minimal downtime throughout its intended service life.
More detailed documentation regarding the product, including the complete technical data sheet and product overview, can be downloaded from resources provided by the manufacturer. These documents offer deeper insight into installation requirements and maintenance procedures.
The V 5780/300 NG4 is a unit that combines performance, reliability, and operational economy, making it an ideal choice for modern natural gas infrastructure.
