A BR 20 Blind rivet adapter (Part No.: 700100) a flagship element of Wieländer+Schill's professional riveting technology, specifically designed for the most demanding riveting tasks where excellent accessibility is crucial. This compact and robust tool is the ideal choice for working environments where tight spaces and hard-to-reach fastening points present the greatest challenge.
The BR 20 adapter is designed to provide maximum flexibility for the user while guaranteeing a reliable and strong connection.
The BR 20 adapter is made indispensable during professional bodywork and sheet metal work by the following properties:
Excellent Accessibility: Thanks to its compact design, it is ideal for working in tight and hard-to-reach areas.
Impressive Pull Force: It has a maximum pull force of 20 kN (kilonewtons), ensuring a durable and secure connection even in high-demand applications.
Full Mobility: The adapter can be freely rotated and swiveled, significantly increasing the flexibility and precision of the work on complex geometries.
Wide Compatibility: Suitable for blind rivets with a shank diameter between 2.0 mm and 4.2 mm.
Robust Design: Thanks to its steel material and surface treatment (blackened), it ensures a long service life and resistance in workshop conditions.
The precise technical parameters of the BR 20 Blind Rivet Adapter are as follows:
| Property | Value | Note |
|---|---|---|
| Part number | 700100 | |
| Pulling Force | 20 kN | |
| Base material | Steel | |
| Surface Treatment | Black Oxide | |
| Length × Width × Height | 165 x 80 x 60 mm | |
| Weight | 0.980 kg | |
| Stroke Length (Stroke) | 22 mm | |
| Swivelling angle | 120° | |
| Locking | 30° | |
| Applicable Rivet Diameter | 2.0 – 4.2 mm | |
| Content | 1 stück |
When purchasing the BR 20 Blind Rivet Adapter, the package includes the following items:
1 pc BR 20 Blind Rivet Adapter (Part No.: 700100)
1 pc 700204 Tool Case (Includes the 4-piece nosepiece set)
The set contains the basic nosepieces for immediate use of the BR 20 adapter:
1 pc 700518 Nosepiece (3.2A)
1 pc 700519 Nosepiece (3.6A)
1 pc 700520 Nosepiece (4.0A)
1 pc 700521 Nozzle (4.5A)
To maximize the efficiency of the BR 20 adapter, additional accessories and alternatives are available:
For different rivet diameters and special applications (e.g., roofing sheet surfaces), the following nozzles are recommended:
700524 Nozzle 3.2C: For 3.2 mm diameter blind rivets, specifically for use on roofing sheet surfaces. Compatible with BR 20 and BR 50 adapters.
700525 Nozzle 3.6C: For 3.6 mm diameter blind rivets, also for application on roofing sheet surfaces. Compatible with BR 20 and BR 50 adapters.
If higher tensile force or a wider rivet diameter range is required, Wieländer+Schill offers the following models:
BR 50 Blind Rivet Adapter (Part No.: 700101):
Excellent accessibility.
Impressive, 50 kN tensile force.
Suitable for rivets with an axial diameter between 2.0 mm and 5.0 mm.
A 7-piece nozzle set (700215) is included as an accessory.
BR 80 Blind Rivet Adapter (Article No.: 700112):
Basic pulling unit for various applications.
Outstanding, 80 kN tensile force.
Features a patented swivel joint.
Application areas: Ultra-light high-strength blind rivets, HUK (Body repair), pulling pins, screws, Magna Grip.
The BR 20 adapter represents the perfect synthesis of precision, maneuverability, and reliable performance in the field of professional repair technologies.
