Car Lift HLW-17o | pneumatic | 3.5 t | 135.5 cm

WS Wieländer+Schill HLW-17o Pneumatic Vehicle Lift – 3.5 Ton Capacity, 135.5 cm Lifting Height

This detailed product description is for the WS Wieländer+Schill model HLW-17o pneumatic vehicle lift presents its technical features and advantages, making it an ideal choice for professional bodywork and service workshops. This model lifts vehicles vertically by the wheels, ensuring stable and safe access to the vehicle underbody and sills.

Product Overview and Key Features

The platforms of the HLW-17o lift are designed to lift the load directly at the wheels, which creates optimal working conditions for body repair work. The wheel contact surfaces are equipped with a robust grid, ensuring excellent grip and load distribution.

A key advantage of the design is that the central section can be lowered, making it possible to perform service work directly at the vehicle sill without the lift structure obstructing access.

Thanks to its 3.5-ton (3500 kg) load capacity, this lift is capable of safely lifting heavier vehicles as well as longer wheelbase models.

Standard Equipment and Durability:

For all HLW lifts, the base frame, the grid-equipped surfaces, and the drive-over protection are galvanized as standard equipment. This surface treatment significantly increases the device's resistance to corrosion, ensuring a long service life even in intensive workshop environments.

Important Installation Note:

For safe and stable operation, the base frame of the lift must be rigidly fastened to the floor (by bolting) to prevent the lift from moving during lifting or loading. The installation process involves lowering and raising the lift base once for optimal adjustment, followed by securing it to the floor.

Technical Data and Specifications

The table below summarizes the critical technical parameters of the HLW-17o pneumatic lift:

Advantages for the Workshop

The HLW-17o lift offers several advantages in the modern service environment:

1. Lifting occurring at the wheels: This method minimizes tension on the vehicle underbody and is ideal for diagnostic and repair work where full vehicle accessibility is crucial.
2. Excellent Accessibility: The foldable center section allows easy access to the sills and the lower parts of the chassis, which is essential for bodywork repairs.
3. Pneumatic Operation: Pneumatic drive ensures fast, reliable, and precise lifting/lowering speed, while keeping the noise level low (< 70 dB(A)).
4. Robust Design: The galvanized base frame and the massive metal structure guarantee long-term, reliable performance.
5. High Capacity: The 3.5-ton capacity covers most passenger cars and smaller commercial vehicles, providing flexibility for the workshop.

This vehicle lift belongs to the professional service and workshop equipment category from Wieländer+Schill, which prioritizes quality workmanship and user-friendly design.
