This detailed product description presents the Wieländer+Schill welding technology accessories, specifically optimized for the resistance spot welding of V2A (stainless steel) sheets. This accessory is an indispensable tool during body repair work where welding thin aluminum or other special metal sheets requires precision and increased welding resistance.
The welding plate with part number 297300 is a specially designed aid that significantly improves the efficiency and quality of the spot welding process, especially for thin materials such as V2A stainless steel or aluminum sheets.
The main function of the plate is to increase the necessary resistance at the welding point, thus achieving more stable, reliable, and precise weld seams. This is critically important for modern vehicle body repairs where material thicknesses are often extremely low.
Increased Welding Resistance: It specifically takes effect during the spot welding of thin aluminum sheets, ensuring proper current distribution and pressure.
Material Compatibility: Ideally suited for V2A (AISI 304 type) stainless steel sheets.
Precise Sizing: The standardized dimensions ensure compatibility with most professional resistance spot welding machines.
Durability: The construction made of V2A stainless steel guarantees a long service life and continuous, reliable performance under workshop conditions.
The precise specifications of the product guarantee users compatibility and performance assurance.
| Property | Value |
|---|---|
| Part number | 297300 |
| Product Name | Welding steel sheet V2A |
| Length | 250 mm |
| Width | 15 mm |
| Thickness (Height) | 0,6 mm |
| Material | V2A (Stainless Steel) |
| Field of application | Resistance Spot Welding (especially for thin sheets) |
This welding plate is an important accessory in the Wieländer+Schill welding technology portfolio, offering outstanding support in the following areas:
Modern vehicle bodies often contain extremely thin steel and aluminum elements. During conventional spot welding procedures, these thin sheets can easily burn through, or adequate cohesive bonding will not form. Using the 0.6 mm thick V2A plate as an insert between the surfaces to be welded increases local resistance. This increased resistance ensures that the welding current concentrates more effectively at the contact point of the two sheets, resulting in a homogeneous and strong weld spot without damaging the surrounding material.
Welding V2A (the generally used designation for AISI 304 stainless steel) requires special attention to preserve corrosion protection and mechanical properties. This welding plate has been specifically optimized for this material group, ensuring that carbide precipitation or a reduction in corrosion resistance typical for stainless steel in the heat-affected zone does not occur during the welding process.
The size of 250 x 15 mm is an ideal dimension for most professional resistance spot welding guns and electrodes. The 0.6 mm thickness minimizes the distance caused by the built-in component, allowing the welding head to exert optimal pressure on the workpieces.
Wieländer+Schill products are the result of high-quality German engineering. During manufacturing, they apply strict quality control procedures, which are also supported by the ISO 9001 quality management system certification. This welding plate also meets the highest professional requirements, ensuring reliable and repeatable results for workshops.
This accessory is the ideal choice for any professional who wants to achieve the highest level of welding quality and material machining accuracy during body repair.
