This detailed product description presents a precisely manufactured tool set, part of the professional tooling range from Wieländer+Schill, specifically designed for preparing riveting processes. The set, consisting of D15 and D16 tools, offers an optimal solution for the punching and forming operations preceding the installation of solid rivets (SR) for applications with a diameter of 6.0 mm.
The D15 + D16 tool set (Part No.: 700230) belongs to the XSeries – Professional Riveting Technology product line, which offers reliable solutions for essential spot welding and riveting technologies in the body construction and repair industries.
This set is a crucial step in the durable and precise installation of Solid Rivets (SR). The process consists of two main phases, which are provided by the elements of the set:
Punching and Forming (D16 Tool): The D16 tool is responsible for preparing the material, creating the precisely sized hole and the basic form for the rivet.
Forming (D15 Tool): The D15 Shaping Punch performs the necessary pre-shaping for Countersunk Solid Rivets (CSR), ensuring a perfect fit and surface smoothness before installation.
The use of the set guarantees results that comply with standards, are repeatable, and reliable, minimizing the possibility of errors in critical structural connections.
The tool set is manufactured according to Wieländer+Schill's quality standards, consisting of components designed for a long service life and high-stress applications.
The set with part number 700230 contains the following two main elements:
| Component | Part number | Function | Application Rivet Type |
|---|---|---|---|
| D15 Forming Punch | 700826 | Forming of Countersunk Solid Rivets (CSR) | Countersunk Solid Rivet (CSR) |
| D16 Punch and Forming Tool | 700809 | Punching and forming of Solid Rivets (SR) | Solid Rivet (SR) |
Part number: 700826
Function: A special shaping punch developed specifically for the preparatory steps required for installing Countersunk Solid Rivets (CSR).
Application Diameter: 6.0 mm.
Advantage: Ensures that the CSR rivet head is flush with the workpiece surface after installation, which can be important for aesthetic and aerodynamic reasons.
Part number: 700809
Function: This universal tool performs the punching and basic forming operation for standard Solid Rivets (SR).
Application Diameter: 6.0 mm.
Advantage: Provides appropriate preparation for inserting the rivet stem into the workpiece and its initial shaping, maximizing the efficiency of the subsequent riveting process.
Wieländer+Schill products are manufactured in accordance with the highest industrial standards. The durability and precision of the tools are strictly checked during the production process. The company's quality management system is certified with ISO 9001, guaranteeing continuous quality assurance. Furthermore, environmentally conscious operation is supported by ISO 14001 certification.
This tool set is the ideal choice for professionals who:
Perform professional, OEM-compatible repairs.
Require high precision and repeatability in riveting work.
Seek long-lasting, wear-resistant tools.
The D15 and D16 tools are optimized for seamless integration with the Wieländer+Schill XSeries professional riveting systems. These tools fit into the precise fixing system of riveting machines (e.g., hydraulic or pneumatic riveting stations), ensuring correct force transmission and workpiece clamping during the process.
Important note: To achieve optimal tool performance, always check the specifications provided by the riveting machine manufacturer regarding maximum pressing force and cycle time.
A Die set D15 + D16 (700230) a fundamental but critically important set for any professional who installs 6 mm diameter solid rivets (SR) or countersunk solid rivets (CSR). The combined use of the two components – the forming punch (D15) and the punching/forming tool (D16) – ensures perfect preparation for a durable and aesthetic connection. Wieländer+Schill quality guarantees the reliability of the tools even under the toughest workshop conditions.
