The J.A. Becker & Söhne V 5345-2/40 type, 11 kW single-stage air compressor is an excellent choice for those seeking a reliable, high-performance compressed air source for industrial applications. This model combines efficiency, long lifespan, and easy maintenance while capable of handling a wide range of volume flow rates and pressures.
This compressor is not a „mass-produced product” (NO 08/15 PRODUCTS), but a carefully designed, premium category equipment that delivers first-class performance in every aspect.
The V 5345-2/40 series was developed under the banner of reliability and efficiency, featuring outstanding functions:
High-Efficiency Cooling: The advanced cooling system ensures optimal operating temperature, minimizing heat loss and increasing the compressor's lifespan. This is especially important under high load, continuous operation.
Fully Automatic Discharge: The built-in automatic drainage function ensures the efficient and safe removal of condensate from the system, thereby reducing the risk of corrosion and the need for manual intervention.
Long Maintenance Intervals: Thanks to the high-quality components and precise design, maintenance intervals have been significantly extended, which reduces downtime and operating costs.
Robust Construction: The single-stage, two-cylinder design of the compressor guarantees stable operation within the specified pressure range.
The specifications of the V 5345-2/40 model detail its capabilities:
| Parameter | Value | Note |
|---|---|---|
| Típus | Single-stage air compressor | |
| Cylinder Arrangement | 1 stage / 2 cylinders | |
| Inlet pressure (Inlet pressure) | 5 / 7.5 bar | Two possible inlet ranges |
| Volume flow (Volume flow) | 1,030 / 1,600 l/min | Depending on the inlet pressure |
| Maximum operating pressure (Max. operating pressure) | 25 / 20 bar | Depending on the inlet conditions |
| Electric motor performance | 11 kW | |
| Rotational speed (Rotational speed) | 1.500 U/min | |
| Flow Rate (Converted) | 61.8 – 154.8 m³/h | Range specified in the product description |
| Operating Pressure (Converted) | 20 – 40 bar | Range specified in the product description |
Note: The flow rate and pressure values change depending on the input conditions (5 bar or 7.5 bar), as indicated in the technical table and product description.
This compressor is an ideal choice for industrial environments requiring reliable, medium-to-high pressure compressed air. The maximum operating pressure between 20 and 40 bar (depending on inlet conditions) enables a wide range of uses, including:
Pneumatic drives: Operation of valves and cylinders requiring high torque.
Industrial processes: Manufacturing processes requiring special pressure air.
Post-compression booster: If existing compressors cannot reach the required final pressure, this model functions as an excellent post-compression booster (Nachverdichter).
The volume flow rate between 61.8 m³/h and 154.8 m³/h ensures that the equipment can flexibly adapt to varying air demands.
J.A. Becker & Söhne is committed to comprehensive support. Further detailed information regarding the product can be downloaded:
Data sheet: Detailed technical specifications and drawings.
Leaflet: Comprehensive product overview with main advantages.
The V 5345-2/40 is a premium category product representing German engineering precision, guaranteeing long-term, trouble-free operation even in the most demanding industrial environments. The equipment's design minimizes service requirements while providing maximum performance.
